11kV Peb Theem Cast Resin Qhuav Hom Fais Fab Transformer
Muaj lus nug? GNEE cov neeg muag khoom muaj nyob rau hauv kev sib tham tam sim no
Xa E-mail:sales@gneeelectric.com
Tel:+8615824687445
SC(B) series epoxy cobqhuav hom fais fab transformeryog nplaim-retardant, hluav taws-pov thawj, tawg-pov thawj, txij nkawm dawb, tsis muaj kuab paug, me me, vim hais tias lub winding yog encapsulated, thiab tuaj yeem ntsia ncaj qha rau hauv qhov chaw thauj khoom. Nyob rau tib lub sijhawm, kev tsim qauv tsim nyog thiab tsim nyog thiab cov txheej txheem casting ua rau cov khoom lag luam tsis tshua muaj paug, qis suab nrov thiab muaj zog cua sov dissipation muaj peev xwm. Nyob rau hauv cov xwm txheej ntawm kev yuam cua txias, nws tuaj yeem ua haujlwm tau ntev hauv qab 125% rated load. Nws yog txawm peem rau nrog ib tug ntse ntsuas kub xws li, uas muaj lub luag hauj lwm ntawm fault alarm, overtemperature tswb, overtemperature mus txawv tebchaws thiab dub box. Nws txuas nrog lub computer los ntawm RS485 serial interface thiab tuaj yeem saib xyuas hauv nruab nrab thiab tswj tau.
SCB 11-30-2500/10kV Peb Theem Epoxy Resin Cast Dry Type Fais Fab Transformer Parameter
|
Rated Peev Xwm (kVA) |
Kev sib txuas pab pawg cim |
Voltage sib xyaw (kV) |
Tsis muaj load tam sim no% |
Tsis muaj load poob W |
Luv-circult impedance% |
||
|
(H.V.) |
Kev kub siab tapping ntau yam |
(L.V.) |
|||||
|
50 |
Yyn0 los yog Dyn11 |
20 |
± 5% lossis 2 x 2.5 |
0.4 |
2.4 |
380 |
6.0 |
|
100 |
2.2 |
600 |
6.0 |
||||
|
160 |
1.8 |
750 |
6.0 |
||||
|
200 |
1.8 |
820 |
6.0 |
||||
|
250 |
1.6 |
940 |
6.0 |
||||
|
315 |
1.6 |
1080 |
6.0 |
||||
|
400 |
1.4 |
1280 |
6.0 |
||||
|
500 |
1.4 |
1500 |
6.0 |
||||
|
630 |
1.2 |
1700 |
6.0 |
||||
|
800 |
1.2 |
1950 |
6.0 |
||||
|
1000 |
1.0 |
2300 |
6.0 |
||||
|
1250 |
1.0 |
2650 |
6.0 |
||||
|
1600 |
1.0 |
3100 |
6.0 |
||||
|
2000 |
0.8 |
3600 |
6.0 |
||||
|
2500 |
0.8 |
4300 |
6.0 |
||||
Peb theem qhuav hom fais fab transformer yam ntxwv
- Lub high voltage winding yog ua los ntawm enameled tooj liab hlau los yog zaj duab xis qhwv tooj liab hlau, thiab lub low voltage winding yog ua los ntawm tooj liab ntawv ci. Lub high voltage winding yog ntim nrog iav fiber ntau. Nyob rau hauv lub tshuab nqus tsev vacuum, epoxy resin tsis muaj muab tub lim yog siv rau pouring, uas ua ib tug tag nrho tom qab kho, nrog rau cov neeg kho tshuab siab zog, me me ib feem ntawm qhov paug thiab muaj kev ntseeg siab.
- nplaim retardant, tawg-pov thawj, tsis muaj kuab paug ib puag ncig, tiv thaiv ib puag ncig. Nws tuaj yeem ntsia tau rau hauv qhov chaw thauj khoom.
- Cov khoom siv tseem ceeb yog ua los ntawm cov khoom zoo siab txias-dov taw qhia silicon steel ntawv nrog cov qauv inclined seam laminated tag nrho.
- Lub kauj tsis nqus dej noo, thiab cov tub ntxhais thiab cov clamp raug kho los ntawm cov txheej txheem tshwj xeeb, uas tuaj yeem ua haujlwm hauv cov av noo siab thiab lwm qhov chaw hnyav. Kev ua haujlwm tsis tu ncua yam tsis muaj kev kho dehumidification.
- Siab tiv taus rau luv luv Circuit Court, xob laim impulse thiab overload.
- Nyias resin rwb thaiv tsev txheej sab hauv thiab sab nraud coil, zoo tshav kub dissipation kev ua tau zoo.
- Kev poob qis, kev txuag hluav taws xob zoo, kev lag luam kev lag luam thiab kev txij nkawm dawb.
- Lub ntim me me, lub teeb yuag, me me hauv pem teb qhov chaw thiab yooj yim installation.
Khoom Paub meej
Ntim & Shipping
Cim npe nrov: 11kv peb theem cam khwb cia resin qhuav hom fais fab transformer, Tuam Tshoj 11kv peb theem cam khwb cia resin qhuav hom fais fab transformer manufacturers, lwm tus neeg, Hoobkas
